Oil pump install question.

Small Block Mopar Engine

  1. FlDart360

    FlDart360 Well-Known Member

    Messages:
    201
    Likes Received:
    101
    Joined:
    May 30, 2016
    Location:
    FL ,Zero Elevation
    Local Time:
    10:23 AM
    Ok so the motor is out of the car and while I’m at it I’m going to change the oil pump. Can someone tell me the dos and don’ts of threading the oil pickup into the new pump? The book I have only address the height and alignment to the pan but says nothing about connecting the pickup to the pump. Do you use any type of thread locker? What are the common mistakes people make? Also would it be prudent to replace the front transmission seal on my 727 before putting the motor back in? Thanks all will check back after work today.

  2. yellow rose

    yellow rose Overnight Sensation FABO Gold Member

    Messages:
    27,939
    Likes Received:
    24209
    Joined:
    Jun 19, 2015
    Location:
    Central Washington
    Local Time:
    7:23 AM
    If it's a stock pan and pick up, the pick up needs to lightly touch the pan. It can't back out if done correctly. You can use some pipe dope on the threads if you want to.

    • Like Like x 1
    • Thanks! Thanks! x 1
    • FlDart360

      FlDart360 Well-Known Member

      Messages:
      201
      Likes Received:
      101
      Joined:
      May 30, 2016
      Location:
      FL ,Zero Elevation
      Local Time:
      10:23 AM

      What about Locktight? Is that to extreme. I think i'm overthinking this.

    • yellow rose

      yellow rose Overnight Sensation FABO Gold Member

      Messages:
      27,939
      Likes Received:
      24209
      Joined:
      Jun 19, 2015
      Location:
      Central Washington
      Local Time:
      7:23 AM

      Yup. Overthinking it. It the pickup is touching the pan, how can it come out? It can't. And if it's a stock pan and pickup, then the pickup needs to be touching the pan.

      • Agree Agree x 1
      • nm9stheham

        nm9stheham Well-Known Member

        Messages:
        12,090
        Likes Received:
        3954
        Joined:
        Dec 20, 2013
        Location:
        Waynesboro, VA
        Local Time:
        10:23 AM
        I would not hesitate to put blue loctite on it.

        • Like Like x 1
        • Agree Agree x 1
        • krazykuda

          krazykuda Well-Known Member FABO Gold Member How-To Section Editor

          Messages:
          58,327
          Likes Received:
          23947
          Joined:
          Aug 20, 2007
          Location:
          Orland Park, IL
          Local Time:
          9:23 AM


          I tape two nickles to the bottom of the pick-up, then test fit the pan so the nickles hit the pan when placed on the block with no gasket to set the pick up height, then remove the nickles and install the pan...

          • Like Like x 1
          • Thanks! Thanks! x 1
          • yellow rose

            yellow rose Overnight Sensation FABO Gold Member

            Messages:
            27,939
            Likes Received:
            24209
            Joined:
            Jun 19, 2015
            Location:
            Central Washington
            Local Time:
            7:23 AM

            That's too far away, per the FSM

            • Thanks! Thanks! x 2
            • krazykuda

              krazykuda Well-Known Member FABO Gold Member How-To Section Editor

              Messages:
              58,327
              Likes Received:
              23947
              Joined:
              Aug 20, 2007
              Location:
              Orland Park, IL
              Local Time:
              9:23 AM
              It's always worked for me...

              I never did see in the service manual where they set the pick up to... Can you let me know where it's at???

            • yellow rose

              yellow rose Overnight Sensation FABO Gold Member

              Messages:
              27,939
              Likes Received:
              24209
              Joined:
              Jun 19, 2015
              Location:
              Central Washington
              Local Time:
              7:23 AM
              image.jpeg image.jpeg image.jpeg image.jpeg I could find it in any service manual, but I grabbed my 1973 off the shelf. So...1973 service manual, page 9-46, 9-47 and 9-48.

              Starting with Engine Oiling Sytem at the bottom of the page...Installation (1) Inspect alignment of of oil strainer (pickup). Bottom of strainer MUST be parallel with the machined surface of the cylinder block. Bottom of the strainer MUST touch the bottom of the pan with 1/16 to 1/8 inch interference.

              Emphasis mine.

              This is why guys have oil pressure issues, think they "suck" the pan dry or a ton of other crap when the fact is they put too much clearance between the pan and the strainer.

              It needs to touch. It's how it's engineered. Just like I've been saying since 1980 in my high school auto shop.

              I've added the pictures because this place is crawling with professional bickerers and people who would argue with a stop sign around here.

              You can't argue with the dudes who engineered the parts. Well, some of you can. And will.

              • Thanks! Thanks! x 4
              • Like Like x 1
              • Agree Agree x 1
              • FlDart360

                FlDart360 Well-Known Member

                Messages:
                201
                Likes Received:
                101
                Joined:
                May 30, 2016
                Location:
                FL ,Zero Elevation
                Local Time:
                10:23 AM

                Thanks this is really helpful I would love to find a true manual like the one pictured.

              • Dicer

                Dicer Back Bone beats Wish Bone all the time. FABO Gold Member

                Messages:
                1,318
                Likes Received:
                1867
                Joined:
                Jan 12, 2016
                Location:
                Land of Lincoln
                Local Time:
                9:23 AM
                • Like Like x 1
                • yellow rose

                  yellow rose Overnight Sensation FABO Gold Member

                  Messages:
                  27,939
                  Likes Received:
                  24209
                  Joined:
                  Jun 19, 2015
                  Location:
                  Central Washington
                  Local Time:
                  7:23 AM

                  You can find them online. I found this one for my current car at a swap meet last April. I also have a few others I keep for reference.

                  • Like Like x 1
                  • RustyRatRod

                    RustyRatRod I was born on a Monday. Not last Monday. FABO Gold Member

                    Messages:
                    70,792
                    Likes Received:
                    45723
                    Joined:
                    Jun 7, 2010
                    Location:
                    Georgia
                    Local Time:
                    10:23 AM
                    I agree 100%. That's what the blue is for. Something you "may" remove again "one day".

                    • Like Like x 1
                    • Thanks! Thanks! x 1
                    • nm9stheham

                      nm9stheham Well-Known Member

                      Messages:
                      12,090
                      Likes Received:
                      3954
                      Joined:
                      Dec 20, 2013
                      Location:
                      Waynesboro, VA
                      Local Time:
                      10:23 AM
                      Interesting about the pickup touching the pan with some degree of interference (the 1/16" to 1/8" as above), to keep pressure on the pickup. I have read that when the /6's came out, that was not being done at the factory and the pickup were just touching the pan. Customers supposedly complained about the odd noise from the lower part of the engine that would come and go. Can't recall if there was a TSB on that or not.....

                      Fast forward: Guess who installed a /6 pickup that was just touching the pan, and who now has a funny noise in the lower part of his /6? LOL

                      • Like Like x 1
                      • yellow rose

                        yellow rose Overnight Sensation FABO Gold Member

                        Messages:
                        27,939
                        Likes Received:
                        24209
                        Joined:
                        Jun 19, 2015
                        Location:
                        Central Washington
                        Local Time:
                        7:23 AM

                        Ford and GM did the same thing with their pick ups. My dad bought my mom a brand new 71 Maverick with an inline 6. Even with an extra quart of oil in the pan, every time you turned to the left the low oil pressure light would come on.

                        Turned out that one got off the assembly line with the pickup 3/8 off the floor of the pan. Set the pick up on the floor of the pan and it ended all that.

                        • Like Like x 2
                        • FlDart360

                          FlDart360 Well-Known Member

                          Messages:
                          201
                          Likes Received:
                          101
                          Joined:
                          May 30, 2016
                          Location:
                          FL ,Zero Elevation
                          Local Time:
                          10:23 AM
                          Ok so I had another first time surprise when I was unbolting the headers. I don’t remember this happening on my small block 289 but I guess it must be a Mopar thing. Coolant coming out of the bolt holes when I removed the headers bolts? I hope this is normal? It wasn’t every hole. Do I just dab some RTV on them when I put things back together?

                        • yellow rose

                          yellow rose Overnight Sensation FABO Gold Member

                          Messages:
                          27,939
                          Likes Received:
                          24209
                          Joined:
                          Jun 19, 2015
                          Location:
                          Central Washington
                          Local Time:
                          7:23 AM
                          Yep. The front and rear holes go to water on those heads. Perfectly normal.

                        • Mattax

                          Mattax Just the facts, ma'am FABO Gold Member

                          Messages:
                          11,727
                          Likes Received:
                          7473
                          Joined:
                          Feb 7, 2013
                          Location:
                          Phila. Pa
                          Local Time:
                          10:23 AM
                          The AMC 360 (and prob all the engines in that family) has a little plastic button riveted into the bottom of the pickup.

                          @FlDart360 One other tip. When installing the pump to the block make sure it stays seated until the bolts are tight.

                          • Agree Agree x 1
                          • yellow rose

                            yellow rose Overnight Sensation FABO Gold Member

                            Messages:
                            27,939
                            Likes Received:
                            24209
                            Joined:
                            Jun 19, 2015
                            Location:
                            Central Washington
                            Local Time:
                            7:23 AM

                            I forgot about that. I've seen engine come in with the button still on and the pickup .375 off the floor. And they wondered why they need an extra quart and a half to keep the oil pressure up on the big end after a pass.

                            Had some BBC's come through with the same complaint. It's a problem.

                          • tattooedguy

                            tattooedguy New Member

                            Messages:
                            2
                            Likes Received:
                            0
                            Joined:
                            May 25, 2019
                            Location:
                            Tofield ab canada
                            Local Time:
                            8:23 AM
                            So what happens if it doesnt touch? Bend it?

                          • Max1196

                            Max1196 Well-Known Member

                            Messages:
                            943
                            Likes Received:
                            672
                            Joined:
                            May 12, 2016
                            Location:
                            Swift Current SK
                            Local Time:
                            8:23 AM
                            Rotate it. And it touches the pan. See the imprint in the muck!
                            100_1364.JPG 100_1366.JPG

                            • Like Like x 1
                            • tattooedguy

                              tattooedguy New Member

                              Messages:
                              2
                              Likes Received:
                              0
                              Joined:
                              May 25, 2019
                              Location:
                              Tofield ab canada
                              Local Time:
                              8:23 AM
                              I assumed it had to be level and touching the pan

                            • FlDart360

                              FlDart360 Well-Known Member

                              Messages:
                              201
                              Likes Received:
                              101
                              Joined:
                              May 30, 2016
                              Location:
                              FL ,Zero Elevation
                              Local Time:
                              10:23 AM
                              I hear that's a common mistake thanks for the reminder.

                            • FlDart360

                              FlDart360 Well-Known Member

                              Messages:
                              201
                              Likes Received:
                              101
                              Joined:
                              May 30, 2016
                              Location:
                              FL ,Zero Elevation
                              Local Time:
                              10:23 AM
                              Since I don’t know how quickly I will get this engine back in the car would it be a good idea to squirt some oil in each cylinder. I don’t know if any antifreeze might have dripped some ware it should not have when I rotated the engine on the stand?

                            • nm9stheham

                              nm9stheham Well-Known Member

                              Messages:
                              12,090
                              Likes Received:
                              3954
                              Joined:
                              Dec 20, 2013
                              Location:
                              Waynesboro, VA
                              Local Time:
                              10:23 AM
                              Certainly, and wipe it all around. When I get coolant in the cylinders, I'll rotate the engine several times and wipe it off the walls repeatedly as the rings push it up.

                              • Agree Agree x 2
                              • Like Like x 1
