Stroker Build... maybe

Small Block Mopar Engine

  1. MPH426

    MPH426 Active Member

    Messages:
    35
    Likes Received:
    16
    Joined:
    Dec 7, 2019
    Location:
    South East Michigan
    Local Time:
    1:23 PM
    A while back... my engine indulged itself in a slight smathering of steel dust. The rocker arm setup was ball and cup. One of the rocker arm balls broke off. The wasn't much dust (.003 .005) that I found, but it was everywhere. Since this happened, I really don't trust the spinning assembly.
    The bare block is being hot tanked. While this is happening, I'm thinking about putting a stroker kit in. The existing pieces parts might be okay, but as long as it's torn down. I might as well look into it. Realize that it's been 35 years since I've owned a hot rod. Back in the day, my nick name was Dirty Mike 'cause I was always working on cars. Pretty much all big blocks. Including the big block 318. :) From what I remember 1966 was the last year for it.
    That said, I have a few questions regarding the 340 that I have not been able to find the info I'm interested in.
    1: How large can the bore be on a 340 without risking issues? My recollection was .060 (for the 440 anyway.. I could be wrong)
    2: How long of a stroke can I get away with, without having to do to much metal removal for clearance of the spinning assembly?

    The jist of this is, I'd like to end up with a 426CID small block. :D
    With a 4.12" bore and a 4" stroke or a 4.07 bore (what it is now) and a 4.1 stroke, either would yield the desired displacement. I have found cranks with both 4 and 4.1 stroke.
    The formula that I used is this: "echo "scale=3 ; (3.14 * 2.060 * 2.060 * 4)*8" | bc -l" This was done on a Linux box where bc is a basic calculator. I adjusted the bore and stroke as necessary.

    If it can't be done safely, not a big deal. :D
    Thanks!

    Last edited: Sep 29, 2021
  2. rumblefish360

    rumblefish360 I have escaped the evil Empire State! FABO Gold Member

    Messages:
    41,732
    Likes Received:
    13978
    Joined:
    Jun 21, 2005
    Location:
    Florida
    Local Time:
    1:23 PM
    1; A sonic check will tell you how far you can go. I had 1 - 340 @.020 that was left with a cylinder wall thickness of .037 & less in thickness in some spots.

    2; How much of the bottom of the cylinder that needs to be ground for clearance can depend on the connecting rod used.

    The biggest stroke small block crank I have seen was a massive 4.25.

    • Like Like x 2
    • Agree Agree x 1
    • Garrett Ellison

      Garrett Ellison Amateur driver on public roadway, do not imitate.. FABO Gold Member

      Messages:
      3,767
      Likes Received:
      2996
      Joined:
      Jan 1, 2018
      Location:
      Southwest VA
      Local Time:
      1:23 PM
      I have found Bore X Bore X .7854 (1/4 Pi) X Stroke X # of cylinders works very well.

      • Like Like x 1
      • rumblefish360

        rumblefish360 I have escaped the evil Empire State! FABO Gold Member

        Messages:
        41,732
        Likes Received:
        13978
        Joined:
        Jun 21, 2005
        Location:
        Florida
        Local Time:
        1:23 PM
        I gave up the pen pad and just use a on line calculator

        • Like Like x 1
        • S'cuder

          S'cuder FABO Gold Member FABO Gold Member

          Messages:
          609
          Likes Received:
          591
          Joined:
          Nov 30, 2013
          Location:
          Upstate
          Local Time:
          1:23 PM
          Volume of a cylinder is pi r squared h, where pi is 3.14, r is 1/2 bore, and h is stroke. Then multiply by the number of cylinders.

        • 70dart340

          70dart340 FABO Gold Member FABO Gold Member

          Messages:
          1,206
          Likes Received:
          719
          Joined:
          Aug 10, 2007
          Location:
          Puget Sound
          Local Time:
          10:23 AM
          3.1415926, if you want to be super accurate....

        • brian6pac

          brian6pac Well-Known Member

          Messages:
          5,668
          Likes Received:
          4027
          Joined:
          Nov 15, 2016
          Location:
          N.E.Ohio
          Local Time:
          1:23 PM
          FYI, found this about Pi on the internet, Some people have more time on there hands than I do.

          How many digits has pi been calculated to? The value of the number pi has been calculated to a new world record length of 31 trillion digits, far past the previous record of 22 trillion. With that being said, what is the 31 trillionth digit of pi? Google announced the milestone on Thursday March 14, also known as Pi Day (3.14).

          • Like Like x 1
          • Thanks! Thanks! x 1
          • S'cuder

            S'cuder FABO Gold Member FABO Gold Member

            Messages:
            609
            Likes Received:
            591
            Joined:
            Nov 30, 2013
            Location:
            Upstate
            Local Time:
            1:23 PM
            Look up the rule for multiplying significant digits. Many of those digits are meaningless.

            • Like Like x 1
            • Agree Agree x 1
            • 70dart340

              70dart340 FABO Gold Member FABO Gold Member

              Messages:
              1,206
              Likes Received:
              719
              Joined:
              Aug 10, 2007
              Location:
              Puget Sound
              Local Time:
              10:23 AM
              I know, but it's a plug for my youngest son. After 2 degrees in June from the U Dub(University of Washington), he's starting his full scholarship for his PhD in Astrophysics at Vanderbilt in Nashville. This kid is costing me a fortune, but my wife and I will pay every dime for his education. He has difficulty changing his oil, but blows us away in math and astronomy. My bad.

              • Like Like x 3
              • flyfish

                flyfish C8H18+N2O = :-D

                Messages:
                2,435
                Likes Received:
                1070
                Joined:
                Apr 16, 2007
                Location:
                Indy
                Local Time:
                1:23 PM
                I would leave as much meat in the block as you can. A friend of mine made a "426" small block (magnum), but I forget where he got the crank. Also, be sure to leave money in the budget to replace those cheap rockers with some quality rockers (Comp pro mags are the ones I use).

                • Agree Agree x 3
                • D-mailman

                  D-mailman Well-Known Member

                  Messages:
                  565
                  Likes Received:
                  18
                  Joined:
                  Aug 24, 2004
                  Location:
                  Lexington,ky.
                  Local Time:
                  6:23 PM
                  Bore X Bore X Stroke X 6.2832 , This for 8 cylinders . Works for me .

                  • Like Like x 2
                  • 33IMP

                    33IMP Well-Known Member

                    Messages:
                    1,845
                    Likes Received:
                    1919
                    Joined:
                    Jul 3, 2020
                    Location:
                    Taxifornia, soon 2b arizona
                    Local Time:
                    10:23 AM
                    If you have to have a 426, i would much prefer the 4.07x4.10 combo. Keep the cylinder walls as thick as possible!
                    I have an acquaintance that ran some BIG small blocks. His 481 ran hard, but his 502 small block didnt last.
                    He's on his second new demon now.

                    • Like Like x 1
                    • Agree Agree x 1
                    • pittsburghracer

                      pittsburghracer FABO Gold Member FABO Gold Member

                      Messages:
                      6,152
                      Likes Received:
                      11718
                      Joined:
                      Apr 20, 2016
                      Location:
                      Freeport, PA.
                      Local Time:
                      1:23 PM
                      Sometimes I read a post and just shake my head. You want to end up with exactly a 426 engine to impress your friends or yourself learn to lie. Hell ya I know it’s a 424 but my friends aren’t smart enough to figure it out.

                      • Agree Agree x 1
                      • furrystump

                        furrystump Well-Known Member

                        Messages:
                        1,462
                        Likes Received:
                        977
                        Joined:
                        Nov 13, 2004
                        Local Time:
                        6:23 PM
                        You can just run a smaller rod end. Chevy or even honda size. I would go to Molnar Industries or K1 or Ohio crankshaft. See what kits would fit the best. I would go more stroke and leave the walls as thick as possible. Then when you have 422 or 434 or 444 just say its 426. I tell people my 410 is a 340.

                        • Like Like x 2
                        • brian6pac

                          brian6pac Well-Known Member

                          Messages:
                          5,668
                          Likes Received:
                          4027
                          Joined:
                          Nov 15, 2016
                          Location:
                          N.E.Ohio
                          Local Time:
                          1:23 PM
                          I have always used 3.1416

                          • Like Like x 1
                          • 33IMP

                            33IMP Well-Known Member

                            Messages:
                            1,845
                            Likes Received:
                            1919
                            Joined:
                            Jul 3, 2020
                            Location:
                            Taxifornia, soon 2b arizona
                            Local Time:
                            10:23 AM
                            When people ask how big my big block chevy is, i tell em its a hundred over 396.
                            Not my fault if they think 415, instead of 496.

                            • Like Like x 1
                            • Heywodja

                              Heywodja The Heartbeat Stops Here FABO Gold Member

                              Messages:
                              925
                              Likes Received:
                              558
                              Joined:
                              Aug 16, 2014
                              Location:
                              Texas
                              Local Time:
                              12:23 PM

                              • Like Like x 3
                              • MPH426

                                MPH426 Active Member

                                Messages:
                                35
                                Likes Received:
                                16
                                Joined:
                                Dec 7, 2019
                                Location:
                                South East Michigan
                                Local Time:
                                1:23 PM
                                Thanks for all the replies. Apparently there's a lot of people who like calculating the cylinder volume. LOL
                                If I do go this route, it would be with the current 4.07" bore and a 4.1" stroke... I'll probably go with something a bit milder. I want to still be able to run pump gas so I need to keep the compression ratio from getting out of hand. Then again, I may just rebuild it as it was. It ran pretty strong.

                                • Like Like x 1
                                • S'cuder

                                  S'cuder FABO Gold Member FABO Gold Member

                                  Messages:
                                  609
                                  Likes Received:
                                  591
                                  Joined:
                                  Nov 30, 2013
                                  Location:
                                  Upstate
                                  Local Time:
                                  1:23 PM
                                  Molnar makes a 4.15" crank with small rod journals for block clearance. You'd need matching rods and probably a custom piston. With your bore, it would give you a hair under 432 cu in.

                                  • Like Like x 2
                                  • pittsburghracer

                                    pittsburghracer FABO Gold Member FABO Gold Member

                                    Messages:
                                    6,152
                                    Likes Received:
                                    11718
                                    Joined:
                                    Apr 20, 2016
                                    Location:
                                    Freeport, PA.
                                    Local Time:
                                    1:23 PM
                                    First thing I would do is make some phone calls to see what is available. This isn’t 2019 anymore and stuff continues to get harder and harder to find in stock. I was going to sell off my 422 rods and crank but have since changed my mind for now till things start coming again.

                                    • Agree Agree x 5
                                    • Like Like x 1
                                    • MPH426

                                      MPH426 Active Member

                                      Messages:
                                      35
                                      Likes Received:
                                      16
                                      Joined:
                                      Dec 7, 2019
                                      Location:
                                      South East Michigan
                                      Local Time:
                                      1:23 PM
                                      @S'cuder & pittsbughracer. Thanks! great suggestions

                                      • Thanks! Thanks! x 2
                                      • mopar65

                                        mopar65 Well-Known Member

                                        Messages:
                                        1,805
                                        Likes Received:
                                        1258
                                        Joined:
                                        Mar 23, 2008
                                        Location:
                                        Laquey MO
                                        Local Time:
                                        12:23 PM
                                        • Like Like x 2
                                        • Thanks! Thanks! x 1
