Need some help from my head machining buddies

Mopar Racers Forum

  1. PRH

    PRH Well-Known Member

    Messages:
    2,709
    Likes Received:
    4149
    Joined:
    Dec 14, 2018
    Location:
    So. Burlington, Vt
    Local Time:
    12:29 PM
    John, the bits are usually in the $30-45 range, depending on what it is.

    Buy the bit with the profile you want, and bring it with your heads to the shop...... and say, “use this”.

    • Agree Agree x 3
    • Like Like x 2
    • replicaracer43

      replicaracer43 Grumpy Old Man

      Messages:
      4,508
      Likes Received:
      3535
      Joined:
      Oct 10, 2008
      Local Time:
      11:29 AM
      Goodson and Silver Seal both sell the cutters with the multiple angles, and there are a BUNCH of different ones to choose from

    • pittsburghracer

      pittsburghracer FABO Gold Member FABO Gold Member

      Messages:
      4,185
      Likes Received:
      7631
      Joined:
      Apr 20, 2016
      Location:
      Freeport, PA.
      Local Time:
      12:29 PM

      Ya I checked out my Goodson book last night and again today.

    • replicaracer43

      replicaracer43 Grumpy Old Man

      Messages:
      4,508
      Likes Received:
      3535
      Joined:
      Oct 10, 2008
      Local Time:
      11:29 AM
      Go online and request a silver seal catalog, you can thank me later!

      • Thanks! Thanks! x 1
      • PRH

        PRH Well-Known Member

        Messages:
        2,709
        Likes Received:
        4149
        Joined:
        Dec 14, 2018
        Location:
        So. Burlington, Vt
        Local Time:
        12:29 PM
        You would just need to verify with the shop you use that they do in fact have the tooling to use that style of cutter.

        That type of tooling is fairly universal these days....... but not “everyone” has it.

        • Like Like x 1
        • PRH

          PRH Well-Known Member

          Messages:
          2,709
          Likes Received:
          4149
          Joined:
          Dec 14, 2018
          Location:
          So. Burlington, Vt
          Local Time:
          12:29 PM
          One of my customers used to have a speed shop/machine shop.
          He sold it off probably 12-15 years ago.
          He kept a small group of his circle track customers that he still does motors for, and he brings me the heads for the guide and seat work for those jobs.
          There is often a little discussion about what angles he wants, and what chamber or bowl cuts that may be needed, etc.

          If you’re looking to have something done a certain way, don’t assume the guy at the machine shop is a mind reader....... have the talk and discuss it.

          • Agree Agree x 1
          • skrews

            skrews Well-Known Member

            Messages:
            1,578
            Likes Received:
            1125
            Joined:
            Jul 20, 2012
            Location:
            Washington state
            Local Time:
            9:29 AM
          • pittsburghracer

            pittsburghracer FABO Gold Member FABO Gold Member

            Messages:
            4,185
            Likes Received:
            7631
            Joined:
            Apr 20, 2016
            Location:
            Freeport, PA.
            Local Time:
            12:29 PM

            Signed up for a catalog. Thanks.

            • Like Like x 1
            • pittsburghracer

              pittsburghracer FABO Gold Member FABO Gold Member

              Messages:
              4,185
              Likes Received:
              7631
              Joined:
              Apr 20, 2016
              Location:
              Freeport, PA.
              Local Time:
              12:29 PM
              9F79C049-9A02-49FD-AC2F-8D1FA3A77330.png I would love to play around with that number 2

            • yellow rose

              yellow rose Overnight Sensation FABO Gold Member

              Messages:
              25,867
              Likes Received:
              21982
              Joined:
              Jun 19, 2015
              Location:
              Under The Gun
              Local Time:
              9:29 AM

              Look at the 50 degree cutters while your looking around.

              • Like Like x 1
              • pittsburghracer

                pittsburghracer FABO Gold Member FABO Gold Member

                Messages:
                4,185
                Likes Received:
                7631
                Joined:
                Apr 20, 2016
                Location:
                Freeport, PA.
                Local Time:
                12:29 PM

                Having so many sets of Edelbrock and now a set of Speedmaster heads laying around I like the ability to interchange parts from head to head. Once I start going away from “standard” valve angles I lose that. Standard angles have been pretty good to me over the years.

              • PRH

                PRH Well-Known Member

                Messages:
                2,709
                Likes Received:
                4149
                Joined:
                Dec 14, 2018
                Location:
                So. Burlington, Vt
                Local Time:
                12:29 PM
                Often times with those cutters that have multiple angles above the seat...... there isn’t enough radial clearance in the chamber before the cutter OD starts carving out the chamber wall.

                Sometimes that’s a problem...... sometimes it’s not.

                Also, many heads will require sinking the valve a fair amount to be able to utilize all the angles.

                Sometimes that causes issues on the top side of the head with regards to tip heights and installed heights.

                It can turn into a “be careful what you wish for” scenario.

                It’s playing with that type of thing where having access to your own machine really comes in handy.

                • Agree Agree x 1
                • pittsburghracer

                  pittsburghracer FABO Gold Member FABO Gold Member

                  Messages:
                  4,185
                  Likes Received:
                  7631
                  Joined:
                  Apr 20, 2016
                  Location:
                  Freeport, PA.
                  Local Time:
                  12:29 PM

                  Don’t ask me why but the piss poor small block Edelbrock type head chamber likes to be sunk a little to slide a 15 degree top cut on it. It’s worth at least 6-8 cfm. My thinking is it raises the airflow up off the chamber floor and avoids crashing into the almost vertical back wall.

                • skrews

                  skrews Well-Known Member

                  Messages:
                  1,578
                  Likes Received:
                  1125
                  Joined:
                  Jul 20, 2012
                  Location:
                  Washington state
                  Local Time:
                  9:29 AM
                  The deshrouding cutter I commonly use has a °15 bottom angle to it. My "go to" performance intake profile is °35 x .080" top °45 x .040" seat °65 x .100" bottom.

                  • Like Like x 2
                  • Agree Agree x 1
                  • pittsburghracer

                    pittsburghracer FABO Gold Member FABO Gold Member

                    Messages:
                    4,185
                    Likes Received:
                    7631
                    Joined:
                    Apr 20, 2016
                    Location:
                    Freeport, PA.
                    Local Time:
                    12:29 PM

                    First off thanks for suggesting Silver Seal. I requested a book as suggested and received it yesterday, great service. I called Goodson today to see if tooling was still available and undateable and he said yes. Looks like for a few hundred dollars in tooling and 175-200.00 for a phase inverter I cut be grinding seats. I told my buddy 2000.00 for the machine plus new tooling was more than I wanted to spend so he said he could drop it to 1500.00 but since he is going south it won’t be available till around May which is fine with me. That gives me more time to think things over. I sold a head and block cutter for him to another friend of ours for 2500.00.

                    • Like Like x 1
                    • moper

                      moper FABO Gold Member FABO Gold Member

                      Messages:
                      15,771
                      Likes Received:
                      1887
                      Joined:
                      Dec 27, 2004
                      Location:
                      eastern CT
                      Local Time:
                      5:29 PM
                      I just sold my Peterson TCM-25 with the better fixture and all tooling and manuals for it. It’s a great machine and you should be able to cut whatever you want. Only real issue is the spindle rpms are preset (gear selection) not fully adjustable like more modern stuff. Also the table floats vs the head but on most old stuff that’s fine.
                      IMO $2k is a lot if it’s been dormant all this time.
